Wheel Loader
K3016T

3800KG


1600KG

KS wheel loader is highly versatile and featuring a perfect mix of power, comfort and reliability, always offer exceptional traction and ultra-low fuel consumption.

Contact Us

MAIN SPECIFICATIONS

K3016T telescopic wheel loader main specifications
Dimensions1Length (with bucket on ground)5700mm
2Overall width1700mm
3Height2580mm
4Wheel base2595mm
5Min ground clearance275mm
Loading performance6Rated load1600kg
7Operating weight3800kg
8Rated bucket capacity0.4m³
9Max. dump height3230/4100mm

Max dump reach765-1200mm
Engine10ModelYunnei DEF Stage V
11Typewater cooled
12Rated power36.8kw@2400rpm
Transmission13TransmissionFixed shaft 265
14Gear shift4 foward,4 reverse
15Max speed30km/h
16Axlewheel reducer axle
Brake17Tire size23.5/70-16
18Parking brakeManual caliper disc brake
19Service brakeGas over oil brake
Specifications and characteristics are subject to change without notice. Please contact us for detailed information.
