Wheel Loader
K3020
5200KG
2200KG

KS wheel loader is highly versatile and featuring a perfect mix of power, comfort and reliability, always offer exceptional traction and ultra-low fuel consumption.

Contact Us

MAIN SPECIFICATIONS

K3020 wheel loader main specifications
Dimensions1Length (with bucket on ground)5600mm
2Overall width2080mm
3Height2810mm
4Wheel base2300mm
5Min ground clearance325mm
Loading performance6Rated load2200kg
7Operating weight5200kg
8Rated bucket capacity1m³
9Max. dump height3200mm

Max dump reach800mm
Engine10ModelYunnei DEF Stage V
11Typewater cooled
12Rated power55kw@2400rpm
Transmission13TransmissionFixed shaft 265
14Gear shift4 foward,4 reverse
15Max speed30km/h
16Axlewheel reducer axle
Brake17Tire size16/70-20
18Parking brakeManual caliper disc brake
19Service brakeGas over oil brake
Specifications and characteristics are subject to change without notice. Please contact us for detailed information.
